EDS-G2005-EL Series 5-port Entry-level Unmanaged Full Gigabit Ethernet Switches with Metal Housing Immediate Dispatch

2 pieces
MOQ
CN¥924.19/pieces >=2 pieces
Price
EDS-G2005-EL Series 5-port Entry-level Unmanaged Full Gigabit Ethernet Switches with Metal Housing Immediate Dispatch
Features Gallery Product Description Request A Quote
Features
Specifications
Private Mold: NO
Products Status: Stock
Ports: ≤ 8
Transmission Rate: 10/100/1000Mbps
Function: POE
Communication Mode: Full-Duplex & Half-Duplex
Switch Capacity: /
Brand Name: /
Place Of Origin: Shanghai, China
Model: EDS-G2005-EL
Product Name: Switch
MOQ: 1 Piece
Warranty: 5 Years
Condition: 100% Brand-new
Highlight:

poe network switch

,

poe networking switch

,

1000mbps network switch
Basic Infomation
Payment & Shipping Terms
Product Description
EDS-G2005-EL Series 5-port Entry-level Unmanaged Full Gigabit Ethernet Switches with Metal Housing
Product Specifications
Attribute Value
Private Mold NO
Products Status Stock
Ports ≤ 8
Transmission Rate 10/100/1000Mbps
Function POE
Communication Mode Full-Duplex & Half-Duplex
Model EDS-G2005-EL
Product Name Switch
MOQ 1 piece
Warranty 5 Years
Condition 100% Brand-new
Place of Origin Shanghai, China
Features and Benefits
  • Full Gigabit Ethernet ports
  • Compact size for easy installation
  • QoS supported to process critical data in heavy traffic
  • IP40-rated metal housing
  • -40 to 75°C wide operating temperature range (-T models)
Ethernet Interface
  • 10/100/1000BaseT(X) Ports (RJ45 connector): 5
  • Full/Half duplex mode
  • Auto MDI/MDI-X connection
  • Auto negotiation speed
Standards
  • IEEE 802.3 for 10BaseT
  • IEEE 802.3u for 100BaseT(X)
  • IEEE 802.3ab for 1000BaseT(X)
  • IEEE 802.1p for Class of Service
  • IEEE 802.3x for flow control
Switch Properties
  • Processing Type: Store and Forward
  • MAC Table Size: 4 K
  • Packet Buffer Size: 1.5 Mbits
Power Parameters
  • Connection: 1 removable 2-contact terminal block(s)
  • Input Current: 0.21 A (max.)
  • Input Voltage: 12/24/48 VDC
  • Operating Voltage: 9.6 to 60 VDC
  • Overload Current Protection: Supported
  • Reverse Polarity Protection: Supported
Physical Characteristics
  • Dimensions: 18 x 81 x 65 mm (0.71 x 3.19 x 2.56 in)
  • Installation: DIN-rail mounting, Wall mounting (with optional kit)
  • Weight: 120 g (0.26 lb)
  • Housing: Metal
EDS-G2005-EL Series 5-port Entry-level Unmanaged Full Gigabit Ethernet Switches with Metal Housing Immediate Dispatch 0 EDS-G2005-EL Series 5-port Entry-level Unmanaged Full Gigabit Ethernet Switches with Metal Housing Immediate Dispatch 1
