Attribute | Value |
---|---|
Private Mold | Yes |
Products Status | Stock |
Ports | 32 |
Transmission Rate | 10/100/1000Mbps |
Function | LACP, POE, QoS, SNMP, stackable |
Communication Mode | Full-Duplex & Half-Duplex |
Switch Capacity | 10g |
Model Number | S6720-32X-LI-32S-AC |
Place of Origin | Shanghai, China |
Switching Capacity | 1.28 Tbit/s |
---|---|
Forwarding Performance | 240 Mpps |
Fixed ports | 32 x 10 GE SFP+ ports |
MAC Address Table | 32K MAC address entries |
VLAN Features | 4,094 VLANs Guest VLAN and voice VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports VLAN mapping Basic QinQ and selective QinQ |
---|---|
IP Routing | Static routing, RIP, and OSPF VRRP Policy-based routing Routing policies |
Interoperability | VLAN-Based Spanning Tree (VBST) (interoperating with PVST, PVST+, and RPVST) Link-type Negotiation Protocol (LNP) (similar to DTP) VLAN Central Management Protocol (VCMP) (similar to VTP) |
