4U Socket Server And Workstation G5500 V7 Generation Fusionserver 24 X 2.5or3.5 SAS SATA Drives
Product Specifications
| Attribute |
Value |
| Private Mold |
Yes |
| Products Status |
Stock |
| Type |
Rack |
| Processor Main Frequency |
Servers |
| Processor Type |
Servers |
| Model Number |
G5500 V7 |
| Place of Origin |
Shanghai, China |
| Size |
Customized Size |
| Color |
Customizable |
| MOQ |
1PCS |
| Warranty |
1 year |
| Lead Time |
1-3 Working Days |
| Package |
Original Packaging |
Product Description
Generation Fusionserver G5500 V7 4U 2-socket AI Server With 10 X Dual-width GPU Cards And 24 X 2.5or3.5 SAS/SATA Drives
Form Factor: 4U AI server
Processor: 2 x 4th/5th Gen Intel® Xeon® Scalable processors, with up to 385 W TDP per processor
Chipset: Emmitsburg PCH
Memory: 32 x DIMMs at up to 5600 MT/s, up to 256 GB per DIMM
Local Storage: Hot-swappable and flexible drive configurations:
- Up to 24 x 2.5″/3.5″ SAS/SATA drives
- Up to 12 x NVMe SSDs and 8 x SATA/SAS drives
Flash storage: dual M.2 SSDs
RAID: RAID 0, 1, 10, 5, 50, 6, and 60; supercapacitors for cache data protection against power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
GPU Card: 10 x dual-width GPU cards
Network: Multiple network expansion capabilities, 3 x OCP 3.0 NICs
PCIe Expansion: Up to 14 x standard PCIe 5.0 slots, including 10 x dedicated slots for GPU cards
Fan Module: 6 or 8 x hot-swappable counter-rotating fan modules in N+1 redundancy
PSU: 4 x 2000 W Platinum/Titanium, 2600 W Platinum, or 3000 W Titanium hot-swappable PSUs in N+N/N+M redundancy
Management: The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening.
- The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0
- Provides a remote management user interface based on HTML5/VNC KVM
- Supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management
- Optional to configure the FusionDirector management software that provides advanced management features
OS: Microsoft Windows Server, SUSE Linux Enterprise Server, Red Hat Enterprise Linux, and Ubuntu
Security: Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, secure boot, and chassis intrusion detection
Operating Temperature: 5℃~35℃(41℉~95℉), compliant with ASHRAE Classes A1/A2
*The highest operating temperature varies depending on the server configuration.
Certification: CCC, CQC, VCCI, and CE
Installation Suite: L-shaped guide rails, adjustable guide rails, and holding rails
Dimensions (H x W x D): 175mm x 447 mm x 898mm (6.89 in. x 17.60 in. x 35.35 in.)
