| Chipset | Access Point |
|---|---|
| Application | Access Point |
| Dimensions | 120mm × 86mm × 26.5mm |
| Power input | PoE power supply: meet 802.3af/at Ethernet power supply standard |
| Maximum power consumption | 6.63W Note: The actual maximum power consumption varies according to the laws and regulations of different countries and regions. |
| Antenna type | Dual frequency omnidirectional antenna |
| Number of users | 256 who can be online at the same time |
| Maximum transmit power | 2.4G: 21dBm (combined power) 5G: 17dBm (combined power) Note: The actual transmit power varies according to the laws and regulations of different countries and regions. |
| Wireless protocol | 802.11a/b/g/n/ac/ac wave2 |
| Maximum rate | 833Mbps |
