USR-G806w Network Router 1000Mbps 4G Cellular Router WiFi 802.11g

2 pieces
MOQ
CN¥1,032.73/pieces >=2 pieces
Price
USR-G806w Network Router 1000Mbps 4G Cellular Router WiFi 802.11g
Features Gallery Product Description Request A Quote
Features
Specifications
Max. Lan Data Rate: 1000Mbps
With Modem Function: Yes
Standards And Protocols: Wi-Fi 802.11g
Wi-fi Supported Frequency: 2.4G & 5G
Supports Wds: Yes
Supports Wps: Yes
Wi-fi Transmission Standard: 802.11b
Wired Transfer Rate: 10/100/1000Mbps
2.4g Wi-fi Transmission Rate: 600Mbps
Encryption Type: WPA2-PSK, WPA2, WPA3, WPA2-Enterprise, WPA-PSK, WPA, WEP, WPA-Enterprise, WPA2-Personal, WPA-Personal, WPA3-Personal
Private Mold: NO
Products Status: New
Type: Wireless
Application: Home
Function: Voip, SDK Available, FireWall, VPN
Lan Ports: 16
Wan Ports: 1 X10/100/1000Mbps
Brand Name: /
Place Of Origin: Shanghai, China
5g Wi-fi Transmission Rate: 1000Mbps
Product Name: Routers
MOQ: 1PCS
Warranty: 1year
Lead Time: 1-3 Working Days
Package: Original Packaging
Highlight:

Network Router 1000Mbps

,

4G Cellular Router WiFi 802.11g

,

USR-G806w
Basic Infomation
Payment & Shipping Terms
Product Description
USR-G806w Network Router 1000Mbps 4G Cellular Router WiFi 802.11g
Key Features:
  • Dual-band WiFi (2.4G & 5G) with 1000Mbps transmission rate
  • 4G cellular connectivity with multiple frequency support
  • 16 LAN ports + 1 WAN port (10/100/1000Mbps)
  • Advanced security protocols (WPA3, WPA2-Enterprise, etc.)
  • Industrial-grade metal casing with IP30 rating
  • Supports VPN, Firewall, and VoIP functionality
Technical Specifications
Attribute Value
Max LAN Data Rate 1000Mbps
Wi-Fi Standards 802.11b/g/n
Frequency Bands 2.4GHz & 5GHz
Encryption Types WPA3, WPA2-Enterprise, WPA-PSK, WEP
LAN Ports 16
WAN Port 1 x 10/100/1000Mbps
Operating Temperature -20℃ to +70℃
Power Supply DC 9-36V
Dimensions 104.0×102.0×28.0 mm
Certifications CE, WPC, RCM, ROHS, WEEE
Network Interface Details
Cellular Interface
Region Supported Bands
Global TDD-LTE: B38/40/41
FDD-LTE: B1/3/7/8/20/28A
WCDMA: B1/8
GSM/EDGE: B3/8
Ethernet Interface
WAN Port: 1×10/100Mbps, IEEE 802.3 compliant, auto MDI/MDIX, 1.5KV isolation protection
LAN Port: 1×10/100Mbps, IEEE 802.3u compliant, auto MDI/MDIX
Wi-Fi Specifications
Standards: IEEE 802.11b/g/n
Frequency: 2.4GHz
MIMO: 2×2
Max Users: 20 simultaneous connections
Physical Characteristics
Housing Material: Metal shell, IP30 rating
Installation: Panel mounting or DIN-Rail mounting
Power Consumption: Average 260mA/12V
Product Images
USR-G806w Network Router 1000Mbps 4G Cellular Router WiFi 802.11g 0 USR-G806w Network Router 1000Mbps 4G Cellular Router WiFi 802.11g 1 USR-G806w Network Router 1000Mbps 4G Cellular Router WiFi 802.11g 2 USR-G806w Network Router 1000Mbps 4G Cellular Router WiFi 802.11g 3 USR-G806w Network Router 1000Mbps 4G Cellular Router WiFi 802.11g 4 USR-G806w Network Router 1000Mbps 4G Cellular Router WiFi 802.11g 5 USR-G806w Network Router 1000Mbps 4G Cellular Router WiFi 802.11g 6 USR-G806w Network Router 1000Mbps 4G Cellular Router WiFi 802.11g 7
