H.265 P2P 8Ch Surveillance Camera System Waterproof IP Camera POE NVR Kit

Product Description

H.265 P2P 8Ch Surveillance Camera System Waterproof IP Camera POE NVR Kit

Product Overview

Professional H.265 P2P 8-channel night vision waterproof IP camera POE NVR kit for comprehensive CCTV security surveillance. Features advanced video compression technology and robust weatherproof construction.

Key Features

H.265/H.264 video compression for efficient storage
8-channel POE NVR system with night vision capability
Waterproof IP cameras for outdoor installation
P2P remote access technology
4K maximum display quality
ONVIF protocol support

Product Attributes

Private Mold

Product Status

Stock

Place of Origin

Shanghai, China

Product Name

CCTV Camera System

Size

Customized Size

Color

Customizable

Technical Specifications

Category		Specification
System	Main processor	Hi3798M
	Operating system	Embedded LINUX operating system
	System resource	Simultaneous multi-channel real-time recording, playback, network operation, USB backup
Interface	Operation interface	16-bit true color graphic menu operation interface, support mouse operation
Interface	Display screen	1/4/8/16
Video	Video input (IP)	45M/84M/43M/16960P
	Video standards	PAL(625TVL,50f/s);NTSC(525TVL,60f/s)
	Video compression	H.265/H.264
	Display quality	Max:4K
	Playback quality	5M/4M/3M/960P
	Decode	25M/24M/43M/4960P
	Motion detection	Depend on camera
Audio	Audio compression	G711A
Audio	Intercom	Unsupport
Record and playback	Record mode	Manual>Alarm>Video Detection>Continuous
	Local playback	25M/24M/43M/4960P
	Search mode	search by Time/calendar/event/channel
Storage and backup	Record Storage	HDD, network
Storage and backup	Backup mode	Network backup, USB hard disk, USB burner, SATA burner
Interface	Video output	1ch HD output (can be extended to support VGA)
	Audio I/O	0/0
	Alarm I/O	0/0
	Network interface	1* 10M/100M Adaptive Ethernet port, 8 POE ports
	USB interface	2*USB2.0 port
	Hard disk	1*SATA (extensible 2 SATA interface) (Up to 8TB for each disk)
Other	PTZ control	Control PTZ device by network
	ONVIF	Available
	Power supply	48V /3 A
	Power Consumption	<10W (Without HDD)
	Work environment	Temperature:0℃- +55℃, Humidity:10% - 90%RH, Atm:86kpa - 106kp
	Dimension	L250W220H45MM
	Weight	1.2KG
