Name: NE40E-X8 Enterprise Router CR5P08BASA71 Including NE40E-X8 Chassis 2 1 Redundant 200G SRU/SFU 4 AC Power Customized Size
Brand: Shanghai Apying Technology Co., Ltd.
SKU: CR5P08BASA71
Price: 1.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Type: Enterprise Router

Use: Enterprise

Network: Bluetooth, Wireless Lan, Wired LAN, ONVIF, SDK

Size: Customized Size

Color: Customizable

Suitable For: Workstation, Laptop, Desktop

Highlight:

customized network router

customized enterprise router

wireless network router

Basic Infomation

Place of Origin: Shanghai, China

Brand Name: /

Model Number: CR5P08BASA71

Payment & Shipping Terms

Gallery

NE40E-X8 Enterprise Router CR5P08BASA71 Including NE40E-X8 Chassis 2 1 Redundant 200G SRU/SFU 4 AC Power Customized Size

Product Description

NE40E-X8 Enterprise Router CR5P08BASA71

Product Overview

The NE40E-X8 Enterprise Router is a high-performance networking solution featuring an NE40E-X8 chassis with 2 redundant 200G SRU/SFU and 4 AC power modules. This customizable router delivers enterprise-grade performance for demanding network environments.

Key Attributes

Type	Enterprise Router
Use	Enterprise
Network	Bluetooth, Wireless LAN, Wired LAN, ONVIF, SDK
Size	Customized Size
Color	Customizable
Suitable for	Workstation, Laptop, Desktop

Product Images

Technical Specifications

Item	NE40E-X16A	NE40E-X8A	NE40E-X3A
Switching capacity	316.5 Tbps	168.8Tbps	120.03 Tbps
Forwarding performance	76800 Mpps	38400 Mpps	11700 Mpps
Slot	22 slots (16 business circuit board slots, 2 main control board slots, 4 switching network board slots)	12 slots (8 business circuit board slots, 2 routing switching board slots, 2 switching network board slots)	5 slots (3 business line cards, 2 main control board slots)
Dimensions (W×D×H)	442mm×650mm×1778mm (40U)	442mm×650mm×930mm (21U)	442mm×710mm×264mm (6U)
Weight	453.8Kg (2T DC)	242kg (2T DC)	74.7 kg (200G)
Interface type	400GE/100GE/50GE/40GE/25GE/10GE LAN/WAN, GE/FE, POS/CPOS/E1/CE1	400GE/100GE/50GE/40GE/25GE/10GE LAN/WAN, GE/FE, POS/CPOS/E1/CE1	100GE/50GE/40GE/25GE/10GE LAN/WAN, GE/FE, POS/CPOS/E1/CE1
IPv4	Supports Static routing, RIP, OSPF, IS-IS, BGP-4 protocols. All ports forward at line speed in complex routing environments
IPv6	Supports IPv4 to IPv6 transition technologies, static/dynamic routing protocols, neighbor discovery, and comprehensive IPv6 management
MPLS	Supports MPLS TE, P2MP-TE/mLDP, MPLS/BGP VPN, L2 VPN technologies including VPLS/VLL, and Multicast VPN
SR/SRv6	Supports SR MPLS, SR Policy, SR TI-LFA, L3VPN over SRV6
Layer 2 Features	IEEE 802.1q/p/3/1ab, STP/RSTP/MSTP, VLAN, G.8032, EVC, VxLAN
QoS	Comprehensive HQoS mechanism with advanced scheduling, traffic supervision, and fine-grained flow identification
Time synchronization	Supports clock synchronization, Ethernet, 1588v2, and Adaptive Clock Recovery (ACR)
