Name: Enterprise Router CR5B0BKP1677 NE40E-X16A Integrated AC Chassis Components 2T Including 6 Fan Tray with Hua Wei 02351PJQ
Brand: Shanghai Apying Technology Co., Ltd.
SKU: CR5B0BKP1677
Price: 1.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Type: Enterprise Router

Use: Enterprise

Network: Bluetooth, Wireless Lan, Wired LAN, ONVIF, SDK

Size: Customized Size

Color: Customizable

Suitable For: Workstation, Laptop, Desktop

Highlight:

wireless network router

customized network router

wireless enterprise router

Basic Infomation

Place of Origin: Shanghai, China

Brand Name: /

Model Number: CR5B0BKP1677

Payment & Shipping Terms

Gallery

Enterprise Router CR5B0BKP1677 NE40E-X16A Integrated AC Chassis Components 2T Including 6 Fan Tray with Hua Wei 02351PJQ

Product Description

Enterprise Router CR5B0BKP1677 NE40E-X16A Integrated AC Chassis Components 2T Including 6 Fan Tray with Hua Wei 02351PJQ

Product Overview

Key Features

Type:

Enterprise Router

Network:

Bluetooth, Wireless LAN, Wired LAN, ONVIF, SDK

Suitable for:

Workstation, Laptop, Desktop

Customization:

Available for size and color

Technical Specifications

Part Number	02351PJQ
Model	CR5B0BKP1677
Description	NE40E-X16A Integrated AC Chassis Components (2T, Including 6 Fan Tray)
First supported version	V800R010C00SPC200
Height	1778 mm
Depth	946 mm
Width	442 mm
Chassis height	40U
Weight (full configuration)	453.3 kg (999.34 lb)
Weight (base)	176.1 kg (302.69 lb)
Switching capacity	81.92 Tbit/s (LPUI-2T)
Power supply mode	AC
Input voltage range	180 V to 264 V
Number of slots	22 (16 service board slots)
Redundancy	Switch fabrics (3+1), Fans (2 partitions), MPUs (1:1), Power supply (9+1)
Operating temperature	0°C to 45°C (32°F to 113°F)
MTBF	22.33 years
Availability	0.9999974444

Power and Thermal Specifications

Configuration	Typical Power Consumption	Maximum Power Consumption	Heat Dissipation
LPUF-480s	9040 W	13720 W	29329.6 BTU/hour
LPUI-1Ts	12390 W	18650 W	40198.4 BTU/hour
LPUI-2Ts	22450 W	28200 W	72837.2 BTU/hour

Environmental Specifications

Storage temperature	-40°C to +70°C (-40°F to +158°F)
Operating humidity	5% RH to 85% RH, non-condensing
Storage humidity	5% RH to 95% RH, non-condensing
Operating altitude	≤ 4000 m (13123.36 ft.)
Noise level	NEBS-compliance (< 78 dBA @ 27°C/80.6°F)
