Customized A23 Dual Band Wi-Fi 6 Repeater Wifi Signal Amplifier with Router Wi-Fi Transmission Standard WiFi 802.11 ax

2 pieces
MOQ
CN¥187.73/pieces >=2 pieces
Price
Customized A23 Dual Band Wi-Fi 6 Repeater Wifi Signal Amplifier with Router Wi-Fi Transmission Standard WiFi 802.11 ax
Features Gallery Product Description Request A Quote
Features
Specifications
Max. Lan Data Rate: 1000Mbps
With Modem Function: NO
Standards And Protocols: WiFi 802.11 Ax
Wi-fi Supported Frequency: 2.4G & 5G
Supports Wds: No
Supports Wps: Yes
Wi-fi Transmission Standard: WiFi 802.11 Ax
Wired Transfer Rate: 1000Mbps
2.4g Wi-fi Transmission Rate: 300 Mbps
Encryption Type: WPA-PSK
Products Status: New
Type: Wireless
Application: MINI WIFI
Function: Voip, FireWall, QoS, VPN, SDK Available
Lan Ports: 3
Brand Name: /
Place Of Origin: Shanghai, China
5g Wi-fi Transmission Rate: 1000Mbps
Product Name: Routers
Size: 123*72*47.5mm
Color: Customizable
Power Consumption: 11W
Highlight:

customized vpn router

,

customized network router

,

4g vpn router
Basic Infomation
Payment & Shipping Terms
Product Description
Customized A23 Dual Band Wi-Fi 6 Repeater

A high-performance WiFi signal amplifier with router capabilities, supporting the latest WiFi 802.11ax standard for enhanced wireless connectivity.

Customized A23 Dual Band Wi-Fi 6 Repeater Wifi Signal Amplifier with Router Wi-Fi Transmission Standard WiFi 802.11 ax 0 Customized A23 Dual Band Wi-Fi 6 Repeater Wifi Signal Amplifier with Router Wi-Fi Transmission Standard WiFi 802.11 ax 1 Customized A23 Dual Band Wi-Fi 6 Repeater Wifi Signal Amplifier with Router Wi-Fi Transmission Standard WiFi 802.11 ax 2
Key Features
  • Dual-band WiFi 6 (802.11ax) technology
  • 2.4GHz (300Mbps) and 5GHz (1201Mbps) frequencies
  • 1000Mbps wired transfer rate
  • 3 LAN ports for wired connections
  • WPA3-SAE/WPA2-PSK security encryption
  • Compact size: 123×72×47.5mm
Technical Specifications
Attribute Value
Max LAN Data Rate 1000Mbps
Wi-Fi Standards WiFi 802.11 ax
Frequency Bands 2.4G & 5G
WPS Support Yes
Encryption Type WPA-PSK
Power Consumption 11W
Dimensions 123×72×47.5mm
Hardware Details
  • Interfaces: 1×10/100/1000Mbps RJ45
  • Antenna: 2×5dBi dual-band antennas
  • Buttons: WPS Button, Reset Button
  • LED Indicator: Signal LED
  • Power Supply: 12V1A, built-in
Wireless Performance
2.4GHz Band
300Mbps transmission rate
≤20dBm transmission power
5GHz Band
1201Mbps transmission rate
≤23dBm transmission power
Operating Modes
Repeater Mode
Access Point Mode
Package Contents
  • 1 × Dual-Band Wi-Fi 6 Range Extender
  • 1 × Quick Installation Guide
Customized A23 Dual Band Wi-Fi 6 Repeater Wifi Signal Amplifier with Router Wi-Fi Transmission Standard WiFi 802.11 ax 3 Customized A23 Dual Band Wi-Fi 6 Repeater Wifi Signal Amplifier with Router Wi-Fi Transmission Standard WiFi 802.11 ax 4
Certifications

FCC, CE, SRRC, ROSH, UCCA compliant
