4U 4 GPU Server 2 X in Tel 5th Xeon Cpu 1 1 Socket E LGA 4677 C741 DDR5 DIMM PCIE 5.0 2000W with 2000W Power Supply

Product Description

4U 4 GPU Server 2 X in Tel 5th Xeon Cpu 1 1 Socket E LGA 4677 C741 DDR5 DIMM PCIE 5.0 2000W with 2000W Power Supply

Product Attributes

Product Description

Technical Specifications

Product Name	SQ4UC741 Server
CPU	Supports fifth and fourth generation scalable processors
CPU Support Type	1+1 Socket E LGA4677
CPU Power Consumption	350W
Chipset	C741 chipset
Memory Capacity	24 DIMM slots up to 6TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM, supports Intel Optane DCPMM
Memory Type	8+8 slots (1DPC)
Maximum Capacity per Module	RDIMM: 96GB, RDIMM-3DS: 2H-128GB/4H-256GB
Maximum Memory Frequency	5600MT/s (1DPC) / 4400MT/s (2DPC) - Fifth generation Intel Xeon Scalable processor 4800MT/s (1DPC) / 4400MT/s (2DPC) - Fourth generation Intel Xeon Scalable processor
Fans	8 pieces with CPU silent fan (automatically adjusts with CPU temperature) and multiple fan speed adjustment controls
Temperature Monitoring	CPU, PCH, MB, CARD Side, i350 temperature sensing
Voltage Monitoring	PSU+12V&+5VSB&+3.3V, +3VSB, PVNN_PCH, P1V05_PCH_STBY, P1VB_PCH_STBY, +BAT, PVCCIN_CPU0, PPVCCIN_CPU1, PVCCINFAON_CPU0, PVCCINFAON_CPU1, PPVCCFA_EHV_FIVRA_CPU0, PVCCFA_EHV_FIVRA_CPU1, PVCCD_HV_CPU0, PVCCD_HV_CPU1
Expansion Slots	SLOT6: PCIE 5.0/CXL1.1 X16 [CPU0] SLOT5: PCIE 5.0/CXL1.1 X16 [CPU1] SLOT4: PCIE 5.0/CXL1.1 X16 [CPU0] SLOT3: PCIE 5.0/CXL1.1 X16 [CPU1] SLOT2: PCIE 5.0/CXL1.1 X16 [CPU1] SLOT0: PCIE 5.0/CXL1.1 X16 [CPU1] SLOT1: PCIE 5.0 X8 [CPU0]
SATA Storage	C741 (up to 13 SATA 6GB/s, supports RAID 0/1/5/10): 3 OCulink for 12 SATA, 1 SATA 7-PIN
Other Features	1 MCIO (PCIE5.0X8) [CPU0] 3 Oculink (PCIE 3.0 x4 or 4SATA 6GB/s) [PCH] 1 M-KEY (PCIE 5.0x4), supports 2280/22110 form factor [CPU0]
