| Attribute | Value |
|---|---|
| Warranty | 1 Year |
| Special Features | POE, Human Motion Tracking, NIGHT VISION, Face detection, Vandal-proof, motion detection, Temperature Measurement, Finger recognition, People Counting, Built-in Siren |
| Sensor | CMOS |
| Style | Floodlight Camera |
| Function | built-in mic, Waterproof / Weatherproof, one-way audio |
| Video Compression Format | H.265 |
| Data Storage Options | NVR, Full HD |
| Customized support | OEM, ODM |
| Lens | Other |
| Material | h.265x, 4mp |
| Application | outdoor, Indoor |
| Frequency | 4mp |
| Model Number | ZC-T4Q9H-N |
| System Structure | Embedded RTOS design, single-core 32-bit DSP, pure hard compression, watchdog, 8MB FLASH, 512MB DDR3 |
| Transducers | 4 million 1/3" CMOS, color 0.001LuxF1.2(AGC ON), black and white 0Lux(IR ON) |
| Video Processing | H.265+/H.265/H.264 video encoding, support dual stream, AVI format; support stream 500k~8000k bps adjustable, support P system and N system |
| Frame Rate | Maximum 30 fps for 4 million and below |
| Image Output | Main stream:2560×1440,2304×1296,1920×1080 Sub stream:800×448,640×480,640×360,352×288 |
| Audio Processing | G.711 codec standard, support audio and video synchronization |
| Supported Protocols | Support HTTP,TCP/IP,IPv4,DHCP,NTP,RTSP,ONVIF,P2P,PPTP,SMTP,GB/T28181 and other network protocols |
| Business Function | Support Web configuration, support for OSD, support for real-time video transmission, support for motion detection alarm linkage, support for motion detection alarm after the center to remind and screen pop-up linkage; support for remote monitoring software (Seetong) and other system applications |
| ONVIF Protocol | Support |
| Client | Support mobile iOS, Android, PC client |
| Other Functions | Human detection |
